NVIDIA RTX A500 Mobile
- Graphics Processor
- GA107S
- Cores
- 2048
- TMUs
- 64
- ROPs
- 32
- Memory Size
- 4 GB
- Memory Type
- GDDR6
- Bus Width
- 64 bit
GPU
Recommended Gaming Resolutions:
- 1920x1080
- 2560x1440
- 3840x2160
The RTX A500 Mobile is a professional mobile graphics chip by NVIDIA, launched on March 22nd, 2022. Built on the 8 nm process, and based on the GA107S graphics processor, the chip supports DirectX 12 Ultimate. The GA107S graphics processor is an average sized chip with a die area of 200 mm² and 8,700 million transistors. It features 2048 shading units, 64 texture mapping units, and 32 ROPs. Also included are 64 tensor cores which help improve the speed of machine learning applications. The card also has 16 raytracing acceleration cores. NVIDIA has paired 4 GB GDDR6 memory with the RTX A500 Mobile, which are connected using a 64-bit memory interface. The GPU is operating at a frequency of 832 MHz, which can be boosted up to 1537 MHz, memory is running at 1500 MHz (12 Gbps effective).
Its power draw is rated at 30 W maximum. This device has no display connectivity, as it is not designed to have monitors connected to it. Rather it is intended for use in laptop/notebooks and will use the output of the host mobile device. RTX A500 Mobile is connected to the rest of the system using a PCI-Express 4.0 x8 interface.
Its power draw is rated at 30 W maximum. This device has no display connectivity, as it is not designed to have monitors connected to it. Rather it is intended for use in laptop/notebooks and will use the output of the host mobile device. RTX A500 Mobile is connected to the rest of the system using a PCI-Express 4.0 x8 interface.
Graphics Processor
Mobile Graphics
- Release Date
- Mar 22nd, 2022
- Generation
-
Ampere-MW
(Ax000)
- Predecessor
- Quadro Turing-M
- Successor
- Ada-MW
- Production
- Active
- Bus Interface
- PCIe 4.0 x8
Relative Performance
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Performance estimated based on architecture, shader count and clocks.
Clock Speeds
- Base Clock
- 832 MHz
- Boost Clock
- 1537 MHz
- Memory Clock
-
1500 MHz
12 Gbps effective
Memory
- Memory Size
- 4 GB
- Memory Type
- GDDR6
- Memory Bus
- 64 bit
- Bandwidth
- 96.00 GB/s
Render Config
- Shading Units
- 2048
- TMUs
- 64
- ROPs
- 32
- SM Count
- 16
- Tensor Cores
- 64
- RT Cores
- 16
- L1 Cache
- 128 KB (per SM)
- L2 Cache
- 2 MB
Theoretical Performance
- Pixel Rate
- 49.18 GPixel/s
- Texture Rate
- 98.37 GTexel/s
- FP16 (half)
- 6.296 TFLOPS (1:1)
- FP32 (float)
- 6.296 TFLOPS
- FP64 (double)
- 98.37 GFLOPS (1:64)
Board Design
- Slot Width
- IGP
- TDP
- 30 W
- Outputs
- Portable Device Dependent
- Power Connectors
- None
- Board Number
- E4728 SKU 10
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 3.0
- Vulkan
- 1.3
- CUDA
- 8.6
- Shader Model
- 6.8
GA107S GPU Notes
| Ray Tracing Cores: 2nd Gen Tensor Cores: 3rd Gen NVENC: 7th Gen NVDEC: 5th Gen PureVideo HD: VP11 VDPAU: Feature Set K Latest Drivers: Windows 7 / 8 / 8.1 (x64): GeForce Release 474.89 Windows 10 / 11 (x64): GeForce Release: Latest Quadro Release: Latest Data Center Release: Latest |
